Technical Specifications:
indicators:
Power supply voltage: 24V (DC)
Measuring range: speed effective value/peak value, range optional
Output current: 4~20mA (loop power supply is proportional to speed effective value/peak value)
Maximum load impedance: 500Ω24VDCpower
supplyFrequency range: 4~1000HzTransverse
sensitivity: < 5%
Natural frequency: 30KHZ
Measurementaccuracy: ±2%,
maximum amplitude: 50g
Sensitive component material: piezoelectric ceramic
Sensitivecomponent structure: shearWiring
method: two-wire current outputPhysical
indicators:
Dimensions: 37×37×22 (mm)
Weight: 300g
Mounting bolts: M6 (customizable)
Casing material: stainlesssteel
Environmental indicators:
Operating temperature: -35 to + 80
Storage temperature: -40 to + 100
Humidity: 95% non-condensing
